5W KLAP Series switching power adapter wide range for Mobile Devices,charger

Place of Origin : China Mainland

Certification : CB , GS , CE , UL , KC, FCC,C-TICK,PSE

Model Number : 5W KLAP Series

MOQ : 1000pcs

Price : Negotiable

Packaging Details : PE bag+ White box

Delivery Time : 35 days

Payment Terms : T/T

Supply Ability : 1Million/month

Contact Now

5W KLAP Series switching power adapter wide range for Mobile Devices,charger OTP OVP OCP SCP

Brand Name:	•
Input:	•Input Voltage : 180 to 264 VAC •Frequency : 47-50/60-63HZ •Input Current : 0.15A (Max) 180VAC •Inrush Current : 60A Max 240VAC at max Load •leakage Current: 0.25mA Max
Output:	•Over temperature protection •Electronic short circuit protection •Average efficiency Measured at 25℃ •Environmental Operating •Operating temperature 0~40℃ Free convection •Operating humidity 10-80% RH Non Condensing •Sea level Non-operating temperature-20~ 80℃
Safety standards:	•Information technology equipment •IEC/EN 61558, UL 61558
Certificates and approvals:	•CB , GS , CE , UL , KC, FCC,C-TICK,PSE
EMI Emission:	•Radiation Test&Conduction Test: EN 55022/FCC Part 15 •Harmonic Test:EN 61000-3-2 •Flicker Test:EN 61000-3-3
EMS immunity:	•ESD Test:EN 61000-4-2 •RS Test:EN 61000-4-3 •EFT Test:EN 61000-4-4 •Surge Test:EN 61000-4-5 •CS Test:EN 61000-4-6 •DIP Test:EN 61000-4-11
Key Applications:	Key Features of KLAP series •Type of equipment for battery charging •Very low no-load loss •No Y capacitor switching power supply design,lower-frequency noise. •Meet the internationally accepted •five-category of energy efficiency standards •Optional Conformal Coating Key Applications of KLAP series It’s suitable for an extremely wide range of applications, including: •Mobile Devices •Charge
Payment Details:	•Payment Terms: T/T,negotiable for OEMs
Main Export Markets:	• Eastern Europe • North America • Mid East/Africa • Central/South America • Asia • Western Europe • Australasia

5W KLAP Series switching power adapter wide range for Mobile Devices,charger

Product Tags:

switching mode power adapter

switching adaptor power supply

China 5W KLAP Series switching power adapter wide range for Mobile Devices,charger wholesale

5W KLAP Series switching power adapter wide range for Mobile Devices,charger Images
