10W KSAFC Series Switching Power Adapters With Wide Range For General I.T.E Use, Set-top-box

Place of Origin : China Mainland

Certification : CB , GS , CE ,BEAB, UL , CCC , FCC,PSE.KC

Model Number : 10W KSAFC Series

MOQ : 1000PCS

Price : Negotiable

Packaging Details : PE bag + White box

Delivery Time : 35 days

Payment Terms : T/T

Supply Ability : 1Million/Month

Contact Now

10W KSAFC Series Switching Power Adapters With Wide Range For General I.T.E Use, Set-top-box,UL60950 approval

Brand Name:	•
Input:	•Input Voltage: 90 to 264 VAC •Frequency : 47-50/60-63HZ •Input Current : 0.3A (Max) 100/240VAC •Inrush Current : 50A Max 100VAC at max Load 60A Max 240VAC at max Load •Leakage Current: 0.25mA Max
Output:	•Over voltage protection •Over current protection at 110-200% of lo and Auto-recovery •Electronic short circuit protection •Operating temperature 0~40℃ Free convection •Operating humidity 10-80% RH Non Condensing •Sea level Non-operating temperature -20~ 80℃
Safety standards:	•Information technology equipment •IEC/EN 60950-1, UL 60950-1, CSA C22.2 No. 60950-1-03 GB4943,K60950
Certificates and approvals:	•CB , GS , CE ,BEAB, UL , CCC , FCC,PSE.KC
EMI Emission:	•Radiation Test&Conduction Test:EN 55022/FCC Part 15 •Harmonic Test:EN 61000-3-2 •Flicker Test:EN 61000-3-3
EMS immunity:	•ESD Test:EN 61000-4-2 •RS Test:EN 61000-4-3 •EFT Test:EN 61000-4-4 •Surge Test:EN 61000-4-5 •CS Test:EN 61000-4-6 •DIP Test:EN 61000-4-11
Key Applications:	Key Features of KSAFC series •Light, extra slim, sleek, compact design •Green power, full complies with CEC level IV, MEPS IV EUP2010 •High power density •Extra safe design, have got their respective safety approvals •Completed protect function Key Applications of KSAFC series •It’s suitable for an extremely wide range of applications, including: •Mobile Devices •Pos •Audio & Video product •ADSL •Set-top-box •Household appliance
Payment Details:	•Payment Terms: T/T,negotiable for OEMs
Main Export Markets:	• Eastern Europe • North America • Mid East/Africa • Central/South America • Asia • Western Europe • Australasia

10W KSAFC Series Switching Power Adapters With Wide Range For General I.T.E Use, Set-top-box
