2A 100V / 240V AC, DC portable USB port switching power adapters (18W)

Place of Origin : Guangdong, China (Mainland)

Model Number : KSAP015

Certification : UL,GS,CE,BEAB,3C

Output Type : DC

Usage : Mobile Phone

Connection : Other

MOQ : 1000 Piece/Pieces

Payment Terms : T/T

Supply Ability : 1000000 Piece/Pieces per Month

FOB : Hong Kong Shenzhen

Price : Negotiable

Packaging Details : PE bag+ white box

Contact Now

Key features of KSAP0151800083D5

●Light, extra slim, sleek, compact design

●Green power, full complies with CEC level V, MEPS IV EUP2011

●High power density

●Extra safe design, have got their respective safety approvals

●Completed protect function

Key Applications ofKSAP0151800083D5

It’s suitable for an extremely wide range of applications, including:

●Mobile Devices

●Printer

●Pos

●Set-top-box

●ADSL

●Hard disk drive

●Audio & Video product

●Household appliance

Input

●Input Voltage: 90to 264 VAC

●Frequency : 47-50/60-63hz

●Input current : 1.2A(Max) 100 /240VAC

●Inrush current : 60AMax 240VAC at max Load

●Leakage current : 0.25 mA Max

Output

●Over voltage protection

●Over current protection

at 110-200% of lo and Auto-recovery

●Electronic short circuit protection

●Operatingtemperature 0~40℃Free convection

●Operating humidity 10-80% RH Non Condensing

●Sea level Non-operating temperature -20~80℃

Safety standards

●Information technology equipment

●IEC/EN 60950-1

Certificates and approvals

●CE, GS, IEC, UL , FCC , PSE, NOM, TUV, PCT, C-TICK, KC, SABS

EMI Emission

●Radiation Test&Conduction Test:EN 55022 /FCC Part15

●Harmonic Test : EN 61000-3-2

●Flicker Test : EN 61000-3-3

EMS immunity

●ESD Test:EN 61000-4-2

●RS Test:EN 61000-4-3

●EFT Test:EN 61000-4-4

●Surge Test:EN 61000-4-5

●CS Test:EN 61000-4-6

●DIP Test:EN 61000-4-11
